Falcon Aerospace
Hawker 800XP inside an EASA Part-145 maintenance hangar
HAWKER · BAE 125 PLATFORM

Hawker 750 / 800XP / 850XP / 900XP

MID-CABIN · TWIN HONEYWELL TFE731 · 2,400-2,930 NM
AIRCRAFT DETAILS

Cabin · Cockpit · Engines

Hawker 800XP cabin interior
CABIN

Mid-cabin stand-up comfort

The Hawker family kept the same internal dimensions across all four variants — 21'3" of usable length, 6'0" wide, 5'9" stand-up. Six- to nine-passenger configurations are typical, with a club-four forward and three-place divan or club-two aft. The 750 trades the ventral fuel tank for an external 32 cu ft baggage pannier.

CABIN LENGTH
21'3"
CABIN WIDTH
6'0"
CABIN HEIGHT
5'9"
MAX PASSENGERS
8-9 typical
BAGGAGE VOLUME
49 cu ft (750: +32 cu ft pannier)
Hawker 850XP flight deck
COCKPIT

Pro Line 21 / SPZ-8000 flight decks

Honeywell SPZ-8000 (800XP) / Collins Pro Line 21 + FMS-6000 (850XP, 900XP, 750)

The 800XP shipped with the Honeywell SPZ-8000 — five-tube EFIS with GPS, GPWS, and TCAS. The 850XP, 900XP, and 750 stepped up to Pro Line 21 with FMS-6000 and full LCD primary flight displays.

  • Pro Line 21 PFD/MFD (850XP+)
  • FMS-6000 with SBAS-WAAS GPS
  • Honeywell SPZ-8000 (800XP)
  • TCAS II with EGPWS
  • ADS-B Out, FANS 1/A+ retrofit available
Honeywell TFE731 engine close-up
PROPULSION

Honeywell TFE731 family

2 × Honeywell TFE731-5BR (800XP/850XP) or TFE731-50R-1H (900XP)4,660 lbf each (900XP: ~4,750 lbf)

The TFE731-5BR has been the Hawker propulsion baseline since 1995. The 900XP's -50R-1H lifted thrust at altitude and improved cruise performance. Falcon coordinates HSI and MPI work with Honeywell.

VARIANT BREAKDOWN

Four variants on the BAE 125 platform

Each variant inherited the previous generation's mission profile and improved on engines, avionics, or fuel/baggage layout.

Hawker 800XP

Generation 1 of 4
EIS1995
Built475
Range~2,540 nm
MTOW28,000 lb

Original modernised BAE 125. TFE731-5BR engines, Honeywell SPZ-8000 avionics. Production 1995-2005.

SPECIFICATIONS

Hawker 900XP — full data sheet

Hawker 800XP side profile
Range2,930 nm
Max CruiseMach 0.80
Service Ceiling41,000 ft
MTOW28,000 lb
Takeoff Distance (MTOW)5,032 ft
Cabin (L × W × H)21'3" × 6'0" × 5'9"
Max Passengers8-9 typical
Engines2 × Honeywell TFE731-50R-1H
AvionicsPro Line 21 / FMS-6000
Year of Introduction1995 (800XP)
Units Built~935 family
FALCON CAPABILITY

How we maintain the Hawker family

Six capability points across the BAE 125 platform — TFE731, Pro Line 21, and the structural know-how earned across hundreds of inputs.

INSPECTION

Phase A/B/C/D signed in-house

Wing-spar, centre-fuselage, ventral tank inspection completed under EASA Part-145.

OEM AUTHORISATION

TFE731 line maintenance

Direct Honeywell engine partnership; HSI/MPI coordination factory-side.

AVERAGE TAT

Phase C TAT: 9 days

Tracked over our last 20 Hawker inputs.

AVIONICS

Pro Line 21 retrofit

Available STC for 800XP airframes; ADS-B Out, FANS 1/A+ packages.

HOURS-ON-TYPE

8,000 hours logged

Across the Hawker family fleet.

AOG

AOG dispatch: 4 hours

Mobile field team launches from Istanbul.

GET IN TOUCH

Pre-purchase, scheduled, or AOG — we are ready

Three ways to reach Falcon Aerospace: book a pre-purchase inspection, schedule a maintenance slot, or call the 24-hour AOG line.

Request a PPI quote
